CNC Turning Service
From prototyping to full production runs. Advanced CNC lathe Turning machine skilled and experienced Programmers will allow you to produce highly accurate, high quality turned and lathe parts to meet even your most stringent requirements. Tik precision is one of the most reliable CNC turning services company near you.
Adopt ISO9001
Quality system certification
China CNC Turning Service
CNC turning services can rotate plastics and metals at high speeds from bars or blocks. The turning procedure allows the creation of complex external and internal geometries, including the creation of various threads. For any round parts, such as for example shafts, worms, balls, CNC turning is a more effective method than CNC milling.Our turning capabilities can produce prototypes through mass production of parts.
Custom CNC Turning Service
On the basis of NC lathe, turning is equipped with tool magazine and manipulator to greatly increase the number of tools that can be selected. The CNC turning center mainly focuses on turning, and can also process milling, drilling, expanding, reaming, tapping and so on. Its machining objects mainly include: conical surface of complex parts and rotating body with complex curve as bus. On the turning center, it can also drill radial holes, mill keyways, mill cam grooves and spiral grooves, taper threads and variable pitch threads. Turning centers generally also have the following two advanced functions.
1) The function of power tool is that some or all tool positions on the tool holder can use rotary tools (such as milling cutter and drill bit) to rotate these tools through the power in the tool holder.2) The c-axis position control function can realize the arbitrary position control of the spindle in the circumferential direction. Realize x-C and z-c linkage. In addition,some turning centers also have Y-axis function.
Tik Precision has a number of advanced CNC lathes with an accuracy of 0.0002''(5um). Professional technical team and quality management system fully guarantee the quality and delivery of customers.
Technological Process
Find out more about our turning process for getting your CNC turned parts made in our How It Works video.
What finishes are available for CNC Milling?
As Machined
Surface roughness can be specified using Ra value. Ra3.2 - 1.6um as standard.
Bead Blast
Bead blast size: 80um as standard. 50-120um available.
Anodised Type 2
Standard: Clear / natural, black, red, green, blue, yellow / gold. Close match to specified RAL numbers.
Anodised Type 3
Standard: Black or Grey. Much duller in look, but has much better surface protection.
CNC Turning Process
CNC Turning Process is a high-precision and high-speed machining way. The automatic lathe machines use digital information to control the displacement of parts and tools. Both plastics and metals from bar or block material can get high-speed turning. The turning process can make the production of complex external and internal geometries, including generating all kinds of threads. For round-shaped components such as shafts, worms, and spheres, CNC turning can show its efficiency, while for CNC milling it shows power in other angular shape parts. Tik precision can make both prototypes and mass production with a CNC turning process.
Our Capacity
01
Tik precision has more than 70 precision CNC equipment, which involves a great number of tool types, including three-axis, four-axis, and five-axis machining centers, drilling and tapping centers, CNC lathes, and more than 30 ordinary machine tools such as lathes, milling machines, drilling machines, and grinders. The equipment has an annual processing capacity of up to one million pieces.
Our State-of-the-art equipment allows us to provide the most precise custom turned parts
Our Ability
02
Tik Precision has a professional team with a decade of CNC experience, we make the work more efficient to save much time and financial cost.
Whether the customer needs to machine 1 or 10,000 CNC turning parts, we have a professional engineers team to provide free technical support.
Processing Case Chart
Tik Precision CNC processes all kinds of turning, drilling, milling, and grinding parts, provides customized services for processing parts in all walks of life, and has rich experience in processing
| Part | Size | Application | Machining Process Used | Material | Specific Feature |
|---|---|---|---|---|---|
| Automotive Lens mold | 120*120*60 (MM) | Automotive light | Five Axis milling | S136 | Mirror Grinding |
| Automotive light guide | 220*220*6 (MM) | Automotive light | Five Axis milling | PMMA | Radius and polish |
| Automotive light reflector | 98*35*28 (MM) | Automotive light | Five Axis milling | Aluminum 6061-T6 | Surface roughness |
| Turbine wheel | 400MM*700MM | Marine | Five Axis milling | Aluminum 7075-T6 | Runout tolerence |
| Impeller | 360MM* | Turbo Centrifugal blower | Five Axis milling | Aluminum 7075-T6 | Runout tolerence |
| Aluminium main valve body | 86.16*35.3*35.3mm | Medical | Turn-milling | Aluminum 6061-T6 | High surface treatment requirment |
